Granite Surface Plate for CMM

Next Product Inquire Now

    Material: granite

    Specification: 1000X750mm-3000X5000mm or customize

    Surface: T-slots

    Hardness of the working surface: HS70

    Surface treatment: ground finish

    Precision grade: 0-1

    Packaging: plywood box


Specification:

For granite:

No.

Width X Lengthmm)

Precision Grade

0

1

Flatness
  (μm)

1

1000X750

6


2

1000X1000

7


3

1000X1200

7


4

1000X1500

8


5

1000X2000

9


6

1500X2000

10


7

1500X2500

11


8

1500X3000

13


9

2000X2000

11


10

2000X3000

13

27

11

2000X4000

16

32

12

2000X5000

19

37

13

2000X6000

22

43

14

2000X7000

25

49

15

2000X8000

27.5

54.5

16

2500X3000

14.5

28.5

17

2500X4000

16.5

33

18

2500X5000

19.5

39

19

2500X6000

22

44

20

3000X3000

15.5

30.5

21

3000X4000

17.5

35

22

3000X5000

20

40
